Atlona AT-HDVS-CAM video conferencing camera 2.07 MP Black 1024 x 768 pixels 30 fps CMOS 25.4 / 2.8 mm (1 / 2.8")
Beskrivelse
Beskrivelse
2.0 interface for video and camera control. The HDVS-CAM seamlessly integrates with the Omega™ Series and OmniStream™ for a complete, automated conferencing system that includes AV and USB extension. The HDVS-CAM delivers high performance, professional-quality imaging with video resolutions up to 1080p @ 30 Hz, as well as fast and accurate auto-focusing, and a fast yet quiet pan and tilt mechanism. This PTZ camera is ideal for a wide range of small to medium-sized meeting spaces, classrooms, and training rooms. The HDVS-CAM is available in black or white.
The HDVS-CAM is part of a family of PTZ cameras that includes the HDVS-CAM-HDBT with HDBaseT output, as well as the HDVS-CAM-HDMI, with HDMI output plus USB 2.0 interface. It includes a handheld IR remote control, plus mounting hardware for convenient on-wall installation. Available as an option is the AT-HDVS-CAM-CMNT for inverted ceiling mounting.
Specifikationer
Specifikationer
| Camera | |
|---|---|
| PTZ control | Yes |
| Auto focusing (AF) modes | Auto, Manual |
| Aperture range (F-F) | 1.6 - 3 |
| Signal-to-Noise Ratio (SNR) | 55 dB |
| Focal length range | 4.7 - 47 mm |
| Field of view (FOV) angle | 60.9° |
| Optical zoom | 10x |
| Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
| Sensor type | CMOS |
| Megapixel (approx.) | 2.07 MP |
| Video | |
|---|---|
| Supported graphics resolutions | 176 x 144, 320 x 180, 320 x 240, 352 x 288, 640 x 360, 640 x 640, 720 x 576, 800 x 600 (SVGA), 960 x 540, 1024 x 576 (WSVGA), 1024 x 768 (XGA) |
| Supported video modes | 720p, 1080p |
| HD type | HD |
| Maximum frame rate | 30 fps |
| Maximum video resolution | 1024 x 768 pixels |
| Design | |
|---|---|
| Pan speed (max) | 180 °/sec |
| Tilt speed (max) | 80 °/sec |
| LED indicators | Power |
| Pan range | -170 - 170° |
| Tilt angle range | -30 - 90° |
| Product colour | Black |
| Ports & interfaces | |
|---|---|
| DC-in jack | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| RS-232 ports | 1 |
| USB 2.0 ports quantity | 1 |
| Power | |
|---|---|
| Power consumption (typical) | 12 W |
| Input current | 1 A |
| DC input voltage | 12 V |
| Power source type | AC |
| Operational conditions | |
|---|---|
| Storage relative humidity (H-H) | 20 - 95% |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage temperature (T-T) | -10 - 60 °C |
| Operating temperature (T-T) | -10 - 50 °C |
| Network | |
|---|---|
| Supported protocols | VISCAPelco-DPelco-P |
| Performance | |
|---|---|
| Certification | CE, FCC |
| Packaging content | |
|---|---|
| AC adapter included | Yes |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 85258900 |
| Weight & dimensions | |
|---|---|
| Weight | 1.4 kg |
| Height | 167.5 mm |
| Depth | 150 mm |
| Width | 150 mm |
