AVer CAM520 Pro2 2 MP Black 1920 x 1080 pixels 60 fps
Beskrivelse
Beskrivelse
Professional conferencing camera for mid-to-large rooms
The CAM520 Pro2 is an industry-leading conferencing camera. Its 24X total zoom, upgraded AVer SmartFrame, Preset Framing, Sony True WDR, IP video streaming, and a PoE port take your video conferencing experience to the next level!
Present Every Detail with an 24X* Total Zoom
Claim your advanced business benefits by presenting products in ultimate clarity and showing full details with an 24X* total zoom. The CAM520 Pro2 provides smoother video imaging than ever with up to 1080p, 60fps quality. Zoom in tightly on every facet of your products to win more business!
Hold Efficient and Safe Meetings with Upgraded AVer SmartFrame
Keep meetings efficient and safe with AVer’s upgraded SmartFrame. This function uses next-generation facial and body detection to automatically frame people who are wearing masks or presenting any facial profile from up to 7~10 meters away!
Smartly track presenters through preset areas by adding a CAM520 Pro2 and its Preset Framing mode. You can set multiple preset viewing areas that the camera will automatically follow presenters through. There’ s no need for a remote control!
Access Video Calls Without the Hassle of Connecting a USB Cable!
AVer Virtual Streaming technology makes the CAM520 Pro2 available as a camera video source for virtual meetings via a single Ethernet connection. Also, a PoE+ port simplifies set up and reduces installation costs.
Share Live Video Online Anytime with IP Streaming
Livestream on YouTube or Facebook! Easily create live video content with the CAM520 Pro2 by using an H.264 RTSP/RTMP stream to your cloud base or on-premise streaming delivery network.
Enterprise-Grade Imaging with True WDR
Enjoy vivid meetings even in high-contrast backlight environments when you use the CAM520 Pro2. Embedded Sony True WDR is effective at up to 120dB, automatically refining highlights, shadows, and white balance. You deserve to experience enterprise-grade imaging in every meeting.
Specifikationer
Specifikationer
| Camera | |
|---|---|
| PTZ control | Yes |
| Number of camera presets | 10 |
| Wide Dynamic Range (WDR) | Yes |
| Closest focusing distance | 1.5 m |
| White balance | Auto, Manual |
| Aperture range (F-F) | 1.8 - 2.8 |
| Flip & mirror | Yes |
| Vertical field of view | 48° |
| Horizontal field of view | 76° |
| Focal length range | 3.9 - 47.3 mm |
| Field of view (FOV) angle | 84.5° |
| Combined zoom | 24x |
| Optical zoom | 12x |
| Megapixel (approx.) | 2 MP |
| Video | |
|---|---|
| Video formats supported | M-JPEG, NV12, YUV, YUY2 |
| Supported video modes | 240p, 360p, 480p, 720p, 900p, 1080p |
| HD type | Full HD |
| Maximum frame rate | 60 fps |
| Maximum video resolution | 1920 x 1080 pixels |
| Design | |
|---|---|
| Country of origin | Taiwan |
| Web-based management | Yes |
| LED indicators | Status |
| Pan range | -170 - 170° |
| Tilt angle range | -30 - 90° |
| Mounting type | Stand |
| Product colour | Black |
| Ports & interfaces | |
|---|---|
| DC-in jack | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| RS-232 ports | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity | 1 |
| Power | |
|---|---|
| Input current | 2 A |
| DC input voltage | 12 V |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power source type | AC |
| Operational conditions | |
|---|---|
| Storage relative humidity (H-H) | 20 - 80% |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| System requirements | |
|---|---|
| Minimum RAM | 4096 MB |
| Minimum processor | Intel Core i5-4460 |
| Minimum processor speed | 3.2 GHz |
| Minimum processor family | Core i5 |
| Other operating systems supported | ChromeOS |
| Mac operating systems supported | Yes |
| Windows operating systems supported | Yes |
| Logistics data | |
|---|---|
| Products per master (outer) case | 2 pc(s) |
| Products per pallet | 72 pc(s) |
| Harmonized System (HS) code | 8517691000 |
| Network | |
|---|---|
| Supported network protocols | RTSP, RTMP |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Performance | |
|---|---|
| Plug and Play | Yes |
| Remote control type | IR |
| Remote control function | Yes |
| Packaging content | |
|---|---|
| Mounting kit | Yes |
| Cable ties included | Yes |
| Quick start guide | Yes |
| Screws included | Yes |
| Warranty card | Yes |
| Cables included | AC, USB |
| Remote control included | Yes |
| Power supply included | Yes |
| Audio | |
|---|---|
| Built-in speaker(s) | Yes |
| Built-in microphone | Yes |
| Weight & dimensions | |
|---|---|
| Weight | 1.48 kg |
| Height | 182 mm |
| Depth | 153 mm |
| Width | 150 mm |
| Remote control dimensions (W x H x D) | 200 x 50 x 21 mm |
| Packaging data | |
|---|---|
| Package type | Box |
| Package weight | 7.45 kg |
| Package height | 308 mm |
| Package depth | 535 mm |
| Package width | 285 mm |
AVer CAM520 Pro2 2 MP Black 1920 x 1080 pixels 60 fps
Nøgle specifikationer
Nøgle specifikationer
-
SKI nummer50070123-10000406
