Avocor S-Series 65" 4k IR LED Interactive Displ interactive whiteboard 165.1 cm (65") 3840 x 2160 pixels Touchscreen
Beskrivelse
Beskrivelse
The Avocor S Series is a part of our portfolio designed to elevate educational environments, combining sleek design with advanced touch technology. Ideal for classrooms, lecture halls, and hybrid learning settings, the S Series ensures every interaction is engaging and intuitive.
Ensure every educational session, whether in-person or remote, is seamless with the Avocor S Series. Its modern aesthetics and robust functionality make it the perfect solution for schools and universities seeking high performance, interactive displays.
Its diverse connectivity options support seamless integration with various educational tools and devices.
Preloaded with applications like Class, Note, Share, and Browse*, the S Series transforms standard lessons into interactive experiences, keeping students engaged and informed.
Specifikationer
Specifikationer
| Display | |
|---|---|
| Technology | Infrared (IR) |
| Pen & touch differentiation | Yes |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Number of simultaneous touchpoints | 40 |
| Touchscreen type | Infrared |
| Touch technology | Multi-touch |
| Touchscreen | Yes |
| Maximum refresh rate | 60 Hz |
| Contrast ratio (typical) | 5000:1 |
| Native aspect ratio | 16:9 |
| LED backlighting type | Direct-LED |
| LED backlight | Yes |
| HD type | 4K Ultra HD |
| Anti-glare screen | Yes |
| Display resolution | 3840 x 2160 pixels |
| Display number of colours | 1.07 billion colours |
| Display brightness | 350 cd/m² |
| Display diagonal | 165.1 cm (65") |
| Computer system | |
|---|---|
| Graphics card | Mali-G52 MP2 |
| Graphics card family | ARM |
| RAM capacity | 8 GB |
| Maximum internal memory | 64 GB |
| Processor cores | 4 |
| Processor architecture | ARM Cortex A76 + ARM Cortex A55 |
| Built-in processor | Yes |
| Operating system version | 13 |
| Operating system installed | Android |
| Audio | |
|---|---|
| Speaker power | 32 W |
| Number of built-in speakers | 2 |
| Built-in speaker(s) | Yes |
| Network | |
|---|---|
| Ethernet LAN | Yes |
| Bluetooth | Yes |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi | Yes |
| Ports & interfaces | |
|---|---|
| RS-232 ports | 1 |
| S/PDIF out port | Yes |
| OPS slot | 1 |
| Line-out | Yes |
| Line-in | Yes |
| VGA (D-Sub) ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery up to | 65 W |
| USB Type-C DisplayPort Alternate Mode | Yes |
| HDMI output ports quantity | 1 |
| HDMI ports quantity | 3 |
| USB Type-C ports quantity | 1 |
| USB connector type | USB Type-A, USB Type-B, USB Type-C |
| USB 2.0 Type-A hub ports quantity | 4 |
| USB 2.0 Type-B Touch ports quantity | 2 |
| HDCP version | 2.2 |
| HDCP | Yes |
| Ergonomics | |
|---|---|
| Wall mountable | Yes |
| Panel mounting interface | 600 x 400 mm |
| VESA mounting | Yes |
| Performance | |
|---|---|
| Operating hours (hours/days) | 16/7 |
| Ambient light sensor | Yes |
| Power | |
|---|---|
| Power consumption (standby) | 0.5 W |
| Power consumption (typical) | 360 W |
| System requirements | |
|---|---|
| Mac operating systems supported | Yes |
| Windows operating systems supported | Windows 10, Windows 11, Windows 8 |
| Mac compatibility | Yes |
| Operational conditions | |
|---|---|
| Storage temperature (T-T) | -20 - 60 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Weight & dimensions | |
|---|---|
| Weight | 34.3 kg |
| Height | 896.6 mm |
| Depth | 87.2 mm |
| Width | 1488.4 mm |
| Packaging data | |
|---|---|
| Package weight | 44.8 kg |
| Package height | 100 mm |
| Package depth | 208 mm |
| Package width | 1628 mm |
| Packaging content | |
|---|---|
| Open Pluggable Specification (OPS) included | No |
| Number of stylus pens | 2 |
| Stylus pen type | Passive |
| Stylus included | Yes |
| Mounting brackets included | Yes |
| Remote control included | Yes |
| Batteries included | Yes |
| Pen tray included | Yes |
| Other features | |
|---|---|
| Country of origin | China |
| Warranty period | 3 year(s) |
