ClickShare CX-50 Gen2 - EU version w/ 2 Buttons, HDMI in, HDMI out, 3x USB-A, USB-C, S/PDIF, 3.5mm, Ethernet LAN 1Gbit, 802.11 a/g/n/ac, 985g
Premium conferencing solution for high-impact rooms
ClickShare CX-50 2nd generation brings flexible wireless conferencing in high-impact meeting spaces and board rooms. When you walk into the meeting room, ClickShare automatically connects you to room devices like cameras, mics, speakers, sound bars and displays.
Start a meeting from your laptop within seconds, using your preferred video conferencing platform. Make hybrid meetings easy, with just one click on the ClickShare Button or the ClickShare App, both for employees and guests.
| Design |
|---|
| Cable lock slot type |
Kensington |
| Cable lock slot |
Yes |
| Product colour |
Black |
| Form factor |
Desktop |
| Features |
|---|
| Concurrent users |
32 user(s) |
| Miracast |
Yes |
| Google Cast |
Yes |
| AirPlay mirroring |
Yes |
| Supported graphics resolutions |
3840 x 2160 |
| Maximum resolution (HDMI) |
3840 x 2160 pixels |
| Network |
|---|
| Maximum operating distance |
30 m |
| Security algorithms |
WPA2-PSK |
| Ethernet LAN data rates |
10,100,1000,2000,2500 Mbit/s |
| Ethernet LAN |
Yes |
| Dual-band |
Yes |
| Frequency band |
2.4, 5 GHz |
| Top Wi-Fi standard |
Wi-Fi 5 (802.11ac) |
| Wi-Fi standards |
802.11a, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Ports & interfaces |
|---|
| DC-in jack |
Yes |
| 3.5 mm (1/8-inch) out |
Yes |
| S/PDIF out port |
Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| Ethernet LAN (RJ-45) ports |
1 |
| HDMI version |
1.4b |
| Number of HDMI outputs |
1 |
| HDMI input ports quantity |
1 |
| Interface |
HDMI |
| Power |
|---|
| Power consumption (standby) |
0.27 W |
| Power consumption (max) |
74.5 W |
| Input voltage |
110 - 220 V |
| Power source type |
AC |
| System requirements |
|---|
| Mobile operating systems supported |
Android 11.0, Android 12.0, Android 13.0, Android 14.0, iOS 14, iOS 14.5, iOS 15, iOS 16 |
| Mac operating systems supported |
Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura, Mac OS X 14.0 Sonoma, Mac OS X 15.0 Sequoia |
| Mac compatibility |
Yes |
| Windows operating systems supported |
Windows 11 Enterprise x64, Windows 10, Windows 11 Home, Windows 10 Education, Windows 11 Pro, Windows 10 Education x64, Windows 11 x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 Enterprise |
| Operational conditions |
|---|
| Storage relative humidity (H-H) |
0 - 90% |
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating relative humidity (H-H) |
0 - 85% |
| Operating temperature (T-T) |
0 - 40 °C |
| Weight & dimensions |
|---|
| Weight |
985 g |
| Height |
39 mm |
| Depth |
202 mm |
| Width |
200 mm |
| Packaging content |
|---|
| Remote control included |
Yes |
| Technical details |
|---|
| Compliance certificates |
CE, Federal Communications Commission (FCC) |
