Biamp Commercial Audio REVAMP1120T 1.0 channels Performance/stage Black
Beskrivelse
Beskrivelse
Our newest single channel professional power amplifier the REVAMP1120T is a unique and versatile design with 1 x 120 watts output power @ 100 volts (or @ 4 ohms). The REVAMP1120T is a class-D amplifier with a built-in galvanic separated toroidal output transformer free of external influences and disturbances. Convection-cooled and excluded from cooling fans this amplifier is reliable, maintenance-free, silent and dust-free.
The rear clip LED indication on the input gain together with the ease of installation via multiple input and link connection options make the REVAMP1120T the preferred installer’s choice. Completely built in a 1U chassis without front control the REVAMP1120T is bound to become a staple in the small and mid-sized fixed install audio market.
Specifikationer
Specifikationer
| Audio | |
|---|---|
| Frequency range | 50 - 2000 Hz |
| Input impedance | 22000 Ω |
| Dynamic power per channel (8 Ohm) | 60 W |
| Dynamic power per channel (4 Ohm) | 120 W |
| RMS power output per channel (8 Ohm) | 60 W |
| RMS power output per channel (4 Ohm) | 120 W |
| Signal-to-Noise Ratio (SNR) | 97 dB |
| Total Harmonic Distortion (THD) | 0.1% |
| Amplifier class | D |
| Peak power per channel | 120 W |
| Audio output channels | 1.0 channels |
| Ports & interfaces | |
|---|---|
| AC (power) in | Yes |
| Speakers connectivity type | Euroblock |
| Technical details | |
|---|---|
| Country of origin | China |
| On/off switch | Yes |
| Rack capacity | 1U |
| Cooling type | Passive |
| Channels quantity | 1 channels |
| Product colour | Black |
| Connectivity technology | Wired |
| Purpose | Performance/stage |
| Power | |
|---|---|
| Power consumption (max) | 200 W |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 115 - 230 V |
| Power source type | AC |
| Weight & dimensions | |
|---|---|
| Weight | 4.6 kg |
| Height | 44 mm |
| Depth | 239 mm |
| Width | 483 mm |
| General | |
|---|---|
| Product family | Commercial Audio |
| Packaging content | |
|---|---|
| Manual | Yes |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 8518402000 |
| Export Control Classification Number (ECCN) | EAR99 |
| Packaging data | |
|---|---|
| Package weight | 6.5 kg |
| Package height | 145 mm |
| Package depth | 334.8 mm |
| Package width | 519.7 mm |
