Biamp Commercial Audio REVAMP2120T 2.0 channels Performance/stage Black
Beskrivelse
Beskrivelse
Immaculate sound performance, extremely reliable, maintenance-free -- this is how we would describe our latest REVAMP2120T. This 2-channel digital power amplifier provides 2 x 120 watts output power @ 100 volts or @ 4 ohms, that can easily be bridged into a powerful 240 watts @ 100 volts or 8-ohm single amplifier. The REVAMP2120T is a convection cooled class-D amplifier without built-in fans which ensures that the amplifier is noiseless and dust-free. The ergonomic and efficient 1U design has a galvanic separated toroidal output transformer built in to avert external influences & disturbances. During the configuration of the input gain the rear clip LED indicator can be used for a fast and easy installation. The multiple inputs and link connectors make the REVAMP2120T a versatile and installer-friendly amplifier superior to any other in the fixed install market.
Specifikationer
Specifikationer
| Audio | |
|---|---|
| Frequency range | 50 - 20000 Hz |
| Input impedance | 22000 Ω |
| Bridge-mode power output per channel (8 Ohm) | 240 W |
| Dynamic power per channel (8 Ohm) | 60 W |
| Dynamic power per channel (4 Ohm) | 120 W |
| RMS power output per channel (8 Ohm) | 60 W |
| RMS power output per channel (4 Ohm) | 120 W |
| Signal-to-Noise Ratio (SNR) | 98 dB |
| Total Harmonic Distortion (THD) | 0.1% |
| Amplifier class | D |
| Peak power per channel | 120 W |
| Audio output channels | 2.0 channels |
| Ports & interfaces | |
|---|---|
| AC (power) in | Yes |
| Speakers connectivity type | Euroblock |
| Technical details | |
|---|---|
| Country of origin | China |
| On/off switch | Yes |
| Rack capacity | 1U |
| Cooling type | Passive |
| Channels quantity | 2 channels |
| Product colour | Black |
| Connectivity technology | Wired |
| Purpose | Performance/stage |
| Power | |
|---|---|
| Power consumption (max) | 300 W |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 115 - 230 V |
| Power source type | AC |
| Weight & dimensions | |
|---|---|
| Weight | 6.1 kg |
| Height | 44 mm |
| Depth | 239 mm |
| Width | 483 mm |
| Indication | |
|---|---|
| LED indicators | Yes |
| General | |
|---|---|
| Product family | Commercial Audio |
| Packaging content | |
|---|---|
| Manual | Yes |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 8518402000 |
| Export Control Classification Number (ECCN) | EAR99 |
| Packaging data | |
|---|---|
| Package weight | 7.9 kg |
| Package height | 145 mm |
| Package depth | 519.7 mm |
| Package width | 334.8 mm |
