MEMS, Cardioid, PoE, Gigabit Ethernet, RJ-45, 230 x 166 x 42 mm, 1220 g
NPX H1100
The NPX H1100 is a 10-button convenience paging station with handheld microphone for use in Qt X and Tesira systems. The H1100 features embedded DSP and on-board memory to support standard and advanced public address functionalities. Digital audio and control data can be transmitted by either AVB or Dante®. The NPX H1100 can store 999 user-configurable page codes and up to 10 prerecorded messages. Additionally, the H1100 supports both tabletop and wall mounting with a removable “foot” that allows the paging station to be mounted flat against any surface, and a K-slot is included for enhanced physical security via an optional Kensington® lock. The NPX H1100 meets convenience paging requirements for facilities of all sizes.
The NPX H1100 complies with the United States Trade Agreement Act (TAA), allowing it to be included in GSA Schedule contractors’ sales bids for the U.S. federal government.
| Microphone |
|---|
| Maximum sound pressure level (1kHz) |
109 dB |
| Microphone Signal-to-Noise Ratio (SNR) |
76 dB |
| Microphone dynamic range |
92 dB |
| Microphone frequency |
150 - 16000 Hz |
| Type |
Conference microphone |
| Ports & interfaces |
|---|
| Device interface |
RJ-45 |
| Connectivity technology |
Wired |
| Performance |
|---|
| Country of origin |
United States |
| Control type |
Buttons |
| Product colour |
Black |
| Sustainability |
|---|
| Sustainability compliance |
Yes |
| Weight & dimensions |
|---|
| Microphone weight |
1.22 kg |
| Height |
42 mm |
| Depth |
166 mm |
| Width |
230 mm |
| Packaging data |
|---|
| Package weight |
1.22 kg |
| Package height |
139.7 mm |
| Package depth |
254 mm |
| Package width |
400.1 mm |
| Packaging content |
|---|
| Number of products included |
1 pc(s) |
| Technical details |
|---|
| Compliance certificates |
CE, Federal Communications Commission (FCC), RoHS |
| Operational conditions |
|---|
| Operating relative humidity (H-H) |
5 - 95% |
| Operating temperature (T-T) |
0 - 40 °C |
| Logistics data |
|---|
| Harmonized System (HS) code |
8517620050 |
| Export Control Classification Number (ECCN) |
EAR99 |
