Biamp Tesira FORTÉ CI
Biamp | Varenummer:
912.0399.900
Beskrivelse
Beskrivelse
20 - 20000 Hz, 108 dB, 207Ω, Black/Red, RS-232, 8ch, 1RU
The TesiraFORTÉ CI is a digital audio server with 12 analog inputs and 8 analog outputs, and includes Acoustic Echo Cancellation (AEC) technology on all 12 inputs. It also includes up to 8 channels of configurable USB audio.
The TesiraFORTÉ CI complies with the United States Trade Agreement Act (TAA), allowing it to be included in GSA Schedule contractors’ sales bids for the U.S. federal government.
Specifikationer
Specifikationer
| Features | |
|---|---|
| Rack capacity | 1U |
| Rack mounting | Yes |
| Product colour | Black, Metallic |
| Output impedance | 207 Ω |
| Input impedance | 8000 Ω |
| Display | |
|---|---|
| Display type | OLED |
| Built-in display | Yes |
| Audio | |
|---|---|
| Dynamic range | 108 dB |
| Total Harmonic Distortion plus Noise (THD+N) | 0.006% |
| Frequency range | 20 - 20000 Hz |
| Network | |
|---|---|
| Supported network protocols | IEEE 802.1X |
| Ethernet interface type | Gigabit Ethernet |
| Ports & interfaces | |
|---|---|
| RS-232 ports | 1 |
| Analog audio output terminal ports | 8 |
| Analog audio input terminal ports | 12 |
| RJ-45 ports quantity | 1 |
| Power | |
|---|---|
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Power consumption (typical) | 35 W |
| Operational conditions | |
|---|---|
| Operating relative humidity (H-H) | 0 - 98% |
| Operating temperature (T-T) | 0 - 40 °C |
| Certificates | |
|---|---|
| Certification | CE marked (Europe)UL und C-UL listed (USA and Canada)RCM (Australia)RoHS Directive (Europe) |
| Weight & dimensions | |
|---|---|
| Weight | 3.63 kg |
| Height | 44 mm |
| Depth | 267 mm |
| Width | 483 mm |
| Packaging data | |
|---|---|
| Package height | 177.8 mm |
| Package depth | 533.4 mm |
| Package width | 406.4 mm |
| Logistics data | |
|---|---|
| Country of origin | United States |
| Export Control Classification Number (ECCN) | EAR99 |
Download
Download
PDF download:
Biamp Tesira FORTÉ CI
