Small tilt wall mount single stud
Installer-inspired Fusion® tilt mount solves top flat panel installation problems, offering flexible adjustments for small displays with a low-profile display mounting solution.
This single stud Fusion® mount hides better behind narrow bezel displays in the 24-32" range. Many installer-friendly features of Fusion in a smaller form to create superior aesthetic results.
The mount incorporates Fusion® favorites like Centris tilt, ControlZone leveling adjustment and ClickConnect Latching.
Diagram
See a simple setup of an interactive classroom that incorporates a Fusion® tilt wall mount into its design. See the diagram
Selection Guide
Ideal for digital signage, hospitality, transportation and corporate settings, find The Fusion® tilt wall mount that's perfect for you. See the guide
| Mounting |
|---|
| Number of displays supported |
1 |
| Maximum weight capacity |
34.02 kg |
| Minimum screen size |
61 cm (24") |
| Maximum screen size |
106.7 cm (42") |
| Mounting type |
Wall |
| Minimum VESA mount |
75 x 75 mm |
| Maximum VESA mount |
300 x 300 mm |
| Ergonomics |
|---|
| Height adjustment |
Yes |
| Height adjustment range |
0 - 25 mm |
| Tilt angle range |
-12 - 2° |
| Design |
|---|
| Product colour |
Black |
| Certification |
ULCERT |
| Weight & dimensions |
|---|
| Width |
361.9 mm |
| Depth |
50.8 mm |
| Depth (min) |
5.1 cm |
| Height |
359.2 mm |
| Packaging data |
|---|
| Package weight |
6.83 kg |
| Logistics data |
|---|
| Harmonized System (HS) code |
85299097 |
