Fanvil X210i IP phone Black, Grey 20 lines LCD

Fanvil  |  Varenummer: X210I

Beskrivelse

X210i, 20 SIP Lines, 1G RJ-45, RJ-9, USB 2.0, PoE, 5V 2A, 309x214x187 mm

X210i is a visualization paging console phone for industry customer. It is equipped with a gooseneck microphone and supports HD hands-free calling. With intelligent programmable DSS buttons, you can set up a one-click call function to improve communication efficiency. It is compatible with the standard SIP protocol and can be used as a monitoring center or host for office manager with functions such as make calls for external & internal phones, two-way intercom, monitoring, and broadcasting. The X210i improves the management efficiency and emergency response capabilities.

Good sound pickup effect
Professional directional gooseneck microphone presents sound with good reproduction, high definition and low noise

HD audio for speakerphone and handset
Newly-added support for Opus and a larger audio cavity bring abundant, strong low frequency effect. The speakerphone adopts full net coverage delivering crystal clear, life-like voice communication.

Unified Designed With Two Side Displays
Convenient operation on X210i with two 3.5" side DSS Key displays, no need to add external extension modules.
· With three page-switch buttons, the side displays allow to set up to 96 DSS keys (32 physical), and plus 10 DSS keys on the main display, up to 106 DSS keys are available in total for BLF, speed dial, group broadcasting function etc.

Video Surveillance
Equipped with video codec H.264, X210i enables to be integrated with multiple IP cameras. With simply a press on the DSS keys, you can view the video of the selected camera in real time.

Remote control of Fanvil SIP video
door phone and barrier gate· X210i enables to be integrated with Fanvil SIP video door phone, so that you can have a two-way talk with visitors and unlock the door from your X210i IP phone if you deem them worthy

· When the license plate recognition fails to open the barrier gate, the driver can contact the management center through the intercom terminal installed at the entrance and exit of the parking lot, and the management center remotely help the driver to open the barrier gate through X210i.

Broadcast commands are
issued instantlyEach broadcast group is displayed on the DSS screen, you can press the DSS keys to select the broadcast group,and use the gooseneck microphone to make a "one-on-one" or "one-to-many" broadcast calls for emergency notifications, suitable for places where coordination is needed for work relationships.

Rich Extension Function Door
Phone IntegrationX210i offers a variety of device connections including Wi-Fi (via Wi-Fi dongle), integrated Bluetooth, EHS headset, USB port for charging smartphone or other devices. Two Gigabit ports allow you to connect your desktop computer or laptop on the phone – no need for extra cabling.

Specifikationer

Design
Product colour Black, Grey
Handset type Wired handset
Product type IP Phone
Performance
Dual-Tone Multi-Frequency (DTMF) modes In-band, Out-of band, SIP info
Phone features
Call waiting Yes
Anonymous call Yes
Phonebook sharing Yes
Call park Yes
Call pick up Yes
Message-waiting indicator (MWI) Yes
Phonebook capacity 2000 entries
Call hold Yes
Call forwarding Yes
Conference call Yes
Redialing Yes
Intercom Yes
Speed dialling Yes
Do not disturb function Yes
Call transfer Yes
Call log entries 1000
Answering machine Yes
Lines quantity 20 lines
Management features
Firmware upgradeable Yes
Keypad number of keys 77
Number of function keys 6
Volume control Buttons
Display
Touchscreen No
Display resolution 480 x 272 pixels
Display diagonal 10.9 cm (4.3")
Display LCD
Audio
Voice codecs AMR, AMR-WB, G.711a, G.711u, G.722, G.723.1, G.726-32, G.729ab, OPUS, iLBC
Noise reduction Yes
Adaptive jitter buffers Yes
Packet loss concealment (PLC) Yes
Echo cancellation Yes
Voice activity detection Yes
Comfort noise generation (CNG) Yes
Microphone frequency 20 - 20000 Hz
Microphone mute Yes
Number of microphones 1
Speakerphone Yes
Video
Video codecs H.264
Video resolutions 352 x 288,640 x 480 pixels
Video call Yes
Network
Quality of Service (QoS) support Yes
Supported network protocols SIP2.0 UDP/TCP/TLS, RTP/RTCP/SRTP, STUN, DHCP, IPv6, LLDP, PPPoE, 802.1x, L2TP, OpenVPN, SNTP, FTP/TFTP, HTTP/HTTPS, TR-069
Networking standards IEEE 802.1x
Syslog Yes
Bluetooth version 2.1+EDR
Bluetooth Yes
Wi-Fi No
Ethernet LAN interface type Gigabit Ethernet
Ethernet LAN data rates 10,100,1000 Mbit/s
Ethernet LAN Yes
Ports & interfaces
RJ-9 ports quantity 2
Ethernet LAN (RJ-45) ports 2
USB 2.0 ports quantity 1
Power
Input current 2 A
Power over Ethernet (PoE) Yes
Operational conditions
Operating temperature (T-T) 0 - 45 °C
Operating relative humidity (H-H) 10 - 95%
Weight & dimensions
Package height 71 mm
Package depth 301 mm
Package width 323 mm
Height 187 mm
Depth 214 mm
Width 309 mm
Packaging content
Cables included LAN (RJ-45)
Number of handles included 1 pc(s)

Download

PDF download:
