LG LAEC018-GN2 Signage Display Digital signage flat panel 4.14 m (163") LED 500 cd/m² Full HD Black WebOS

LG  |  Varenummer: LAEC018-GN2
Stregkode: 8806091786159,8806084350145

Vælg størrelse

Beskrivelse

All-in-One LED Display, 163”, 1920 x 1080 px, 190 kg, 9W + 9W, 3604 × 2029 × 45.5 mm

All-in-One LED Screen with Built-in Speaker
LG’s LED All-in-One LAEC series has two size of screens; 136- inch and a 163-inch. The LAEC series is offered as an all-in-one package including an embedded controller and built-in speaker. Eliminating the prejudice that LED displays are difficult and complex to install, it doesn't require controller connections or module configuration. After a simple installation process, all you need to do is to turn on the screen with a remote control like home TV.

High Performance with webOS
Built-in Quad Core SoC (System on Chip) can execute several tasks at once for providing smooth content playback. Also, LG webOS Smart Platform enhances user convenience with intuitive GUI and provides to SI or/and developers simple app development tools* such as SDK (Software Development Kit), SCAP, sample applications.

Easy Installation
The installation process of the All-in-One Smart series is very simple. After securing cabinets (two for LAEC015, three for LAEC018), attach each LED display module to them. Lastly, plug in the power cable. This simple installation saves time and labor, thereby making users handle the LED screen with ease.

Specifikationer

Display
Rated lifetime 100000 h
Pixel pitch 1.88 x 1.88 mm
Viewing angle, vertical 160°
Viewing angle, horizontal 160°
Contrast ratio (typical) 3000:1
HD type Full HD
Display brightness 500 cd/m²
Display resolution 1920 x 1080 pixels
Display technology LED
Display diagonal 4.14 m (163")
Audio
RMS rated power 18 W
Number of built-in speakers 2
Built-in speaker(s) Yes
Design
Placement supported Indoor
Product colour Black
Product design Digital signage flat panel
Performance
International Protection (IP) code IP30
Purpose Universal
Power
Heat dissipation 7506 BTU/h
AC input frequency 50/60 Hz
AC input voltage 100 - 240 V
Power consumption (max) 2200 W
Power consumption (typical) 880 W
Computer system
Operating system installed WebOS
Computer system type System on Chip (SoC)
Computer system Yes
Weight & dimensions
Display weight 190 kg
Display height 2029 mm
Display depth 45 mm
Display width 3604 mm
Operational conditions
Operating relative humidity (H-H) 10 - 90%
Operating temperature (T-T) 0 - 40 °C
Certificates
Certification CE, FCC, ETL, CB

Download
