Logitech Tap
Beskrivelse
Beskrivelse
Transform focus and small rooms to a Teams meeting place with one-touch join, always-on readiness, and center of room control. Systems include everything you need to deploy Microsoft Teams Room video conferencing: Logitech MeetUp conferencecam, PC and mount with cable retention, the Logitech Tap touch controller, and 90 days of initial integration and configuration support through the Logitech JumpStart service.
Featuring a 10.1” touchscreen and silent, fan-free design, Logitech Tap connects to the host PC with a 10-meter (32.8 ft) plenum-rated Logitech Strong USB cable. Optimized for the seating layouts and acoustics found in smaller rooms, MeetUp mounts at the display and delivers HD video and clear audio, while RightSight™ auto-framing keeps everyone in the picture.
A range of mounts and audio extensions, plus solutions optimized for medium and large rooms, means you can equip every meeting space in the workplace with touch-controlled Microsoft Teams Room.
Specifikationer
Specifikationer
| Display | |
|---|---|
| Display diagonal | 25.6 cm (10.1") |
| Display technology | IPS |
| Display resolution | 1280 x 800 pixels |
| LED backlight | Yes |
| Viewing angle | 85° |
| Display brightness | 400 cd/m² |
| Contrast ratio (typical) | 1000:1 |
| Touchscreen | Yes |
| Touchscreen technology | Capacitive |
| Number of simultaneous touchpoints | 10 |
| Fingerprint resistant | Yes |
| Anti-glare surface | Yes |
| Design | |
|---|---|
| Housing colour | Black |
| VESA mounting | Yes |
| Panel mounting interface | 100 x 100 mm |
| Cable lock slot type | Kensington |
| Cable lock slot | Yes |
| Motion sensor | Yes |
| Oleophobic coating | Yes |
| Position angle | 14° |
| Performance | |
|---|---|
| Windows operating systems supported | Yes |
| Audio | |
|---|---|
| Built-in microphone | No |
| Built-in speaker(s) | Yes |
| Camera | |
|---|---|
| Built-in camera | No |
| Network | |
|---|---|
| Wi-Fi | No |
| Wi-Fi standards | Not supported |
| Bluetooth | No |
| Ethernet LAN | Yes |
| Ports & interfaces | |
|---|---|
| HDMI input ports quantity | 1 |
| RJ-45 ports quantity | 1 |
| 3.5 mm connector | Yes |
| Power | |
|---|---|
| Power source type | AC |
| Weight & dimensions | |
|---|---|
| Width | 244 mm |
| Depth | 179 mm |
| Height | 58 mm |
| Weight | 1.25 kg |
| Packaging data | |
|---|---|
| Package width | 240 mm |
| Package depth | 370 mm |
| Package height | 122 mm |
| Package weight | 2.89 kg |
| Packaging content | |
|---|---|
| Cables included | AC, HDMI, LAN (RJ-45), USB Type-A to USB Type-C |
| Packaging content | Logitech Tap with Cat5e Kit Tap Touch Controller Cat5e Kit - Logitech Tap Receiver - Dongle Transceiver - 100-240v Power Supply with International Adaptor Set - 2.97 m Cat5e Cable - 7.0 m Cat5e Cable HDMI 1.4a cable 2.0 m VESA Mounting Screws (4) Microfiber Cloth Documentation |
| Logistics data | |
|---|---|
| Master (outer) case width | 260 mm |
| Master (outer) case height | 255 mm |
| Master (outer) case length | 384 mm |
| Master (outer) case gross weight | 6.29 kg |
