92" IPS DLED 5120 x 2160, 500 cd/m2, 1.07B, 178º/178º, RockChip RK3588 Octa-Core, 128GB eMMC, DDR4 8GB
The CDE92UW is an ultrawide 92” digital display delivering stunning image performance with 5K resolution. Designed for both corporate and commercial use, it features a 21:9 aspect ratio, providing 33% more screen real estate than a comparable 16:9 display, making it ideal for Microsoft Teams Rooms and Front Row Mode. Powered by an octa-core SoC running Android 13, the CDE92UW enables seamless multitasking with a USB-C port that delivers 100W and multiple wireless content sharing options. It also supports daisy chaining and comes pre-installed with ViewSonic Manager, a centralized platform that streamlines corporate communication and enhances operational efficiency.
| Display |
| Display diagonal |
2.34 m (92") |
| Display brightness |
500 cd/m² |
| Display number of colours |
1.07 billion colours |
| Display resolution |
5120 x 2160 pixels |
| Anti-glare screen |
Yes |
| LED backlight |
Yes |
| Panel type |
IPS |
| LED backlighting type |
Direct-LED |
| Native aspect ratio |
21:9 |
| Contrast ratio (typical) |
5000:1 |
| Response time |
6.5 ms |
| Viewing angle, vertical |
178° |
| Viewing angle, horizontal |
178° |
| Working area |
2141.952 x 903.636 mm |
| Haze rate |
25% |
| Hardness |
3H |
| Computer system |
| Operating system installed |
Android |
| Operating system version |
13 |
| Built-in processor |
Yes |
| Processor architecture |
ARM Cortex A76 + ARM Cortex A55 |
| Processor cores |
8 |
| Maximum internal memory |
128 GB |
| RAM capacity |
8 GB |
| RAM type |
DDR4 |
| Audio |
| Built-in speaker(s) |
Yes |
| Number of built-in speakers |
2 |
| Speaker power |
20 W |
| Built-in subwoofer |
Yes |
| Subwoofer RMS power |
2 W |
| Projector |
| Built-in projector |
No |
| Ports & interfaces |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity |
4 |
| HDMI ports quantity |
4 |
| HDMI output ports quantity |
1 |
| DisplayPorts quantity |
1 |
| Line-in |
Yes |
| Line-out |
Yes |
| RS-232 ports |
1 |
| Ergonomics |
| Product colour |
Black |
| VESA mounting |
Yes |
| Panel mounting interface |
800 x 600 mm |
| Weight & dimensions |
| Width |
2182 mm |
| Depth |
85.2 mm |
| Height |
943.8 mm |
| Weight |
43.4 kg |
| Packaging data |
| Package width |
2360 mm |
| Package depth |
225 mm |
| Package height |
1072 mm |
| Package weight |
63 kg |
| Quantity per pack |
1 pc(s) |
| Packaging content |
| Manual |
Yes |
| Logistics data |
| Pallet gross width |
2.38 m |
| Pallet gross length |
114 cm |
| Pallet gross height |
128.5 cm |
| Products per master (outer) case |
1 pc(s) |
