WyreStorm EXP-SP-0102-8K video splitter HDMI 2x HDMI

WyreStorm  |  Varenummer: EXP-SP-0102-8K
Stregkode: 0814303016251,814303016251

Specifikationer

HDMI 2.1, HDCP 2.3, EDID, 10240 x 4320, 60 Hz, HDR10+, Dolby Vision, Dolby Atmos, 3.5 W, 12 V DC, 1 A, Black

Our EXP-SP-0102-8K packs a punch as it is a powerful plug-and-play 8K HDMI splitter that has the ability to send uncompressed up to 8K@60Hz or 4K@120Hz up to two displays, but the most useful feature of this splitter is that the second output can scale content down from either 8K>4K or 4K>1080p! Furthermore, its compatible with DSC (Display Stream Compression) version 1.2a pass-through, an approved method of compression in accordance to the HDMI 2.1 specification, allowing up to a lossless 10K@120Hz signal to be transmitted.

Tailored for RETAIL

Split captivating 8K source content between two 8K displays in the retail environment to showcase the powerful capabilities of the emerging resolution in consumer TV’s on the show floor.

SCALING SOLUTIONS

As early adopters of 4K and 8K signal distribution, we know that retrofitting is important in the dawn of new resolution standards. With our splitter, you can rest assured that you won??t be forced to upgrade all displays or AVRs to 8K to reap its benefits. Just set the splitter to downscale to 4K and enjoy 8K content while supporting 4K at the same time!

EDID MANAGEMENT

Display compatibility is the last thing you need to worry about. Our splitter gives you 5 EDIDs that can be adjusted via dipswitches. The splitter also supports Smart EDID, which will auto-negotiate EDIDs based on the detected displays and adjust accordingly.

8K AND BEYOND

Our Essentials 8K splitter not only meets 8K demands but they??re empowered with DSC passthrough, an approved method found in the HDMI 2.1 specification to transmit super-high bandwidth content (up to 10K@120Hz!) producing mathematically lossless content.

COMPLETE YOUR SETUP

WyreStorm offers HDMI 2.1 cables in a number of different lengths and flavors. Use our passive 2.1 cables for short distances up to 3m (9ft). If you need to go a long distance take advantage of our Active Optical 2.1 cables that can reach 15m (50ft).

Ports & interfaces
HDMI version 2.1
Video out 2x HDMI
Video port type HDMI
Video ports quantity 3
Features
Dolby technologies Dolby Atmos, Dolby Vision
Data transfer rate 40 Gbit/s
High Dynamic Range (HDR) technology Dolby Vision, High Dynamic Range 10+ (HDR10 Plus), Hybrid Log-Gamma (HLG)
High Dynamic Range (HDR) supported Yes
Extended display identification data (EDID) Yes
HDCP version 2.3
Maximum refresh rate 60 Hz
Maximum resolution 10240 x 4320 pixels
Product colour Black
Power
Power consumption (max) 3.5 W
Output current 1 A
Output voltage 12 V
Packaging data
Quantity per pack 1 pc(s)
Packaging content
AC adapter included Yes
